型号 频率 饱和功率 1dB压缩点功率 增益 增益平坦度 电压 驻波 货期
（GHz） （dBm，最小值） （dBm，最小值） （dB，最小值） （±dB，典型值） （VDC） （最大值） （周）
FD-0.1-3000-25-26 0.0001~3 – 26 25 ±4 28 2 2~8
FD-5-500-46-37S 0.005~0.5 37 – 46 ±2 24~28 2 2~8
FD-30-1000-45-30S 0.03~1 30 – 45 ±2.5 28 2 2~8
FD-100-18000-30-24 0.1~18 – 24 30 ±3.5 12 2 2~8
FD-100-18000-30-30 0.1~18 – 30 30 ±2.5 12 2 2~8
FD-100-18000-56-24 0.1~18 – 24 56 – 12 2 2~8
FD-400-8000-40-22 0.4~8 – 22 40 ±1.5 12 1.8 2~8
FD-500-2500-46-43 0.5~2.5 – 43 46 ±2.5 32 2 2~8
FD-750-6000-35-35 0.75~6 – 35 35 ±3.5 50 2 2~8
FD-800-6000-25-15 0.8~6 – 15 25 ±1 12 2 2~8
FD-950-2150-25-25 0.95~2.15 – 25 25 ±1.5 5 2 2~8
FD-1000-4000-40-40S 1~4 40 – 40 ±2 +50 or +28 2 2~8
FD-1000-18000-35-30 1~18 – 30 35 ±2 12 2 2~8
FD-1000-26500-28-24 1~26.5 – 24 28 ±1.5 12 2 2~8
FD-1800-2200-46-45S 1.8~2.2 45 – 46 ±1 30 1.5 2~8
FD-2000-3000-33-33 2~3 – 33 33 ±3 30~32 2 2~8
FD-2000-18000-40-40S 2~18 40 – 40 ±3 32 2 2~8
FD-2300-4200-53-47.8S 2.3~4.2 47.8 – 53 ±2.5 50 2 2~8
FD-2500-2700-50-47.8S 2.5~2.7 47.8 – 50 ±1 32 2 2~8
FD-2700-2900-42-50S 2.7~2.9 50 – 42 ±1 32 1.8 2~8
FD-6000-18000-25-26S 6~18 26 – 25 ±1 12 2 2~8
FD-6000-18000-33-26S 6~18 26 – 33 ±1 12 2 2~8
FD-6000-18000-45-47S 6~18 47 – 45 – 28 2 2~8
FD-18000-22000-35-13 18~22 – 13 35 ±1 5 2 2~8
FD-18000-22000-40-33 18~22 – 33 40 ±1 6 2 2~8
FD-18000-26500-15-23 18~26.5 – 23 15 ±1 9 1.8 2~8
FD-18000-26500-30-30 18~26.5 – 30 30 – 8 2 2~8
FD-18000-26500-40-40 18~26.5 – 40 40 ±2 8 2 2~8
FD-18000-26500-45-40S 18~26.5 40 – 45 ±3 28, -5 2 2~8
FD-18000-40000-20-20 18~40 – 20 20 – 6 2 2~8
FD-18000-40000-30-20 18~40 – 20 30 ±2 5 2 2~8
FD-18000-40000-30-27 18~40 – 27 30 ±2.5 12 2 2~8
FD-18000-40000-30-30 18~40 – 30 30 ±2.5 6 2 2~8
FD-20000-32000-22-21 20~32 – 21 22 ±2.5 5 2 2~8
FD-20000-32000-25-21 20~32 – 21 25 ±1 8 1.5 2~8
FD-20000-40000-33-29S 20~40 29 – 33 ±2.5 5 2 2~8
FD-24000-26000-30-30 24~26 – 30 30 – 8 2 2~8
FD-24000-26000-30-32 24~26 – 32 30 – 8 2 2~8
FD-25000-28000-18-25 25~28 – 25 18 – 6 2 2~8
FD-26500-40000-18-23 26.5~40 – 23 18 ±1.5 6 1.8 2~8
FD-26500-40000-27-27 26.5~40 – 27 27 ±2 6.5 2 2~8
FD-26500-40000-30-26S 26.5~40 26 – 30 ±2 6 2 2~8
FD-27500-31200-25-25 27.5~31.2 – 25 25 ±1 12 2 2~8
FD-29000-31000-35-30 29~31 – 30 35 ±1 6 2 2~8
FD-36000-50000-20-30 36~50 – 30 20 ±1.5 5 2 2~8
FD-37000-40000-45-34-F 37~40 – 34 45 – 6 2 2~8
FD-39000-40000-40-33 39~40 – 33 40 – 6 2 2~8
FD-40000-50000-20-20 40~50 – 20 20 – 6 2 2~8
FD-40000-50000-45-29S 40~50 29 – 45 ±2 5~6 2 2~8
FD-40000-53000-40-18S 40~53 18 – 40 ±2 5 2 2~8
FD-40000-60000-40-20S 40~60 20 – 40 ±2.5 15 2 2~8
FD-61000-65000-18-26S 61~65 26 – 18 ±1 5 2 2~8
FD-61000-65000-20-20S 61~65 20 17 20 ±1.5 5 2 2~8
